2500V Insulating High Temperature Resisting Silicone Resin Fiberglass Tubing
Fiberglass sleeving is made of E-class fiberglass sleeve treated at high temperature with a special kind of silicone resin, it possess outstanding a temperature classification of 200℃. It also has excellent properties of self-extinguishing and flexibility.
Application
Dimension
Internal Diameter (mm) | Wall Thickness(mm) |
Size | Tolerances | 1.5KV | 2.5KV | (Meter/Roll) |
1.0 | +0.20 | 0.25±0.05 | 0.30±0.05 | 200 |
1.5 | +0.20 | 0.25±0.05 | 0.35±0.05 | 200 |
2.0 | +0.20 | 0.30±0.05 | 0.35±0.05 | 200 |
2.5 | +0.30 | 0.30±0.05 | 0.35±0.05 | 100 |
3.0 | +0.30 | 0.30±0.05 | 0.35±0.05 | 100 |
3.5 | +0.30 | 0.30±0.05 | 0.35±0.05 | 100 |
4.0 | +0.30 | 0.30±0.05 | 0.35±0.05 | 100 |
4.5 | +0.30 | 0.30±0.05 | 0.45±0.05 | 100 |
5.0 | +0.40 | 0.35±0.05 | 0.45±0.05 | 100 |
6.0 | +0.40 | 0.35±0.05 | 0.45±0.05 | 100 |
7.0 | +0.40 | 0.35±0.05 | 0.45±0.05 | 100 |
8.0 | +0.40 | 0.35±0.05 | 0.45±0.05 | 50 |
9.0 | +0.40 | 0.35±0.05 | 0.45±0.05 | 50 |
10.0 | +0.50 | 0.40±0.05 | 0.50±0.05 | 50 |
11.0 | +0.50 | 0.40±0.05 | 0.50±0.05 | 50 |
12.0 | +0.50 | 0.40±0.05 | 0.50±0.05 | 50 |
13.0 | +0.50 | 0.40±0.05 | 0.50±0.05 | 50 |
14.0 | +0.50 | 0.40±0.05 | 0.50±0.05 | 50 |
15.0 | +0.50 | 0.40±0.05 | 0.50±0.05 | 50 |
16.0 | +0.50 | 0.40±0.05 | 0.50±0.05 | 50 |
17.0 | +0.60 | 0.45±0.05 | 0.55±0.05 | 50 |
18.0 | +0.60 | 0.45±0.05 | 0.55±0.05 | 50 |
19.0 | +0.60 | 0.45±0.05 | 0.55±0.05 | 50 |
20.0 | +0.60 | 0.50±0.05 | 0.55±0.05 | 50 |
25.0 | +0.60 | 0.55±0.05 | 0.60±0.05 | 25 |
30.0 | +1.0 | 0.70±0.1 | 1.0±0.10 | 25 |
35.0 | +1.0 | 0.80±0.1 | 1.1±0.10 | 25 |
Why Choose Us:
1. You can get the perfect material according to your requirement at the least possible price.
2. We also offer Reworks, FOB, CFR, CIF, and door to door delivery prices. We suggest you to do deal for shipping which will be quite economical.
3. The materials we provide are completely verifiable, right from raw material test certificate to the final dimensional statement.(Reports will show on requirement)
4. e guarantee to give a response within 24hours(usually in the same hour)
5. You can get stock alternatives, mill deliveries with minimizing manufacturing time.
6. We are fully dedicated to our customers. If it will not possible to meet your requirements after examining all options, we will not mislead you by making false promises which will create good customer relations.
